Product Details:
Payment & Shipping Terms:
|
| Material: | Carbon Steel | Type: | Horizontal Roller Conveyor |
|---|---|---|---|
| Structure: | Roller | Load Capacity: | 200kgs |
| Material Feature: | Oil Resistant | Certification: | CE Certificate |
| Shaft: | 12mm | Frame Material: | Stainless Steel |
| Roller Pitch: | 75 100 MM | Dimension(L*W*H): | Customized Size |
| After Warranty Service: | Video Technical Support, Online Support | ||
| High Light: | Rotary Free Conveyor Belt Rollers,Oil Resistant Conveyor Belt Rollers,200kgs Stainless Steel Conveyor Roller |
||
Stainless Steel Conveyor Roller Rotary Free Carrier Roller with Heavy Duty
Technical parameters:
bend angle:90 degree
bend radius:900mm
frame: 90mm U-STEEL
width: 300mm~800mm
Load capacity: max about 100kg
| SPE. | bend radius R |
OD(φ)×wall T(t) production |
shaft OD(φ)×shell thickness(t) | roller width W |
||||
| R-TCN | 900 | 12x1.0pipe semi-circle |
[ 90×30×3.2 100 |
300~800 100 increasing |
||||
| roller pitch P (roller QUT) |
roller angle θ |
roller strength (kg) |
conveyor weight (kg) |
||
| 75(23)/100(18) 150(12) |
90° | 100 (400W) |
55.7 (400W / 75P) |
||
Roller Type:
Size:
| roller widthW (mm) | 100 | 200 | 300 | 400 | 500 | 600 | 700 | 800 | |
| Conveyor widthW+75 (mm) | 175 | 275 | 375 | 475 | 575 | 675 | 775 | 875 | |
| Roller capacity (kg) |
135 | 120 | 110 | 90 | 70 | 60 | 50 | 45 | |
| Conveyor weight 3,000L (kg) |
75P | 29.8 | 38.2 | 42.7 | 51.2 | 59.7 | 67.5 | 75.9 | 80.4 |
| 100P | 25.9 | 32.3 | 35.8 | 42.3 | 48.7 | 54.6 | 61.0 | 64.4 | |
| Roller weight(g) | 380 | 561 | 742 | 923 | 1,104 | 1,285 | 1,466 | 1,647 |
|
Carrier roller:
1) Easy installation and nice flexibility;
2) Low friction coefficient and water-proof;
3) Fine welding technique ensure roller with low vibration and noise
4) Electrostatic spraying technology makes the roller more durable and good-looking;
5) Strict inspection standard ensures our high quality product
