Replace AES BSFG Full Graphite Bellow 2.5Mpa Pump Mechanical Seal

KL-BSFG Bellow Cartridge Seal Replace AES BSFG Full Graphite Mechanical Seal

KL-BSFG cartridge seal is specifically designed to eliminate the costly and often long lead-time issues of exotic elastomer compounds. This seal features graphite rings at every primary sealing surface, eliminating the need for elastomers.

The hydraulically balanced bellows unit is available in a variety of different material options with either elastomer or graphite packing sealing rings.

Features:

Full graphite seal for high temperature or corrosive chemical applications

Fits pumps with thin radial seal chamber cross-sections

Quench, flush and drain ports for cooling or heating options to maximize seal life

cartridge design for ease of installation

Sizes available from 1.000" to 4.000" (24mm - 100mm) in standard and ANSI Plus gland formats

Operating range:

Temperature:-75℃～425℃

Speed:≤23m/s

Pressure: ≤2.5Mpa

Shaft diameter: 1.000" to 4.000"

Material:

Rotary face:Carbon/Sic/TC

Stat Ring:Sic/TC

Product Drawing:

We supply repair service:

Fixing and Applying Directions of Mechanical Seals

1) Select Appropriate mechanical seal to match the materials according to work conditions and host machine equipment.
2) The radial acting deviation for the shaft(shaft sleeve) of the installed mechanical seal shall be 0.04mm by maximum
while the axial movement value of the rotor shall be no more than 0.1mm.
3) The seal cover (or shaft cover) of the stationary ring of the installed mechanical seals,the vertical degree of the seal
face should be 0.04mm by maximum.
4) When installing the mechanical seals,the shaft(shaft sleeve),seal chamber,seal face as well as the mechanical seal
must be cleaned in order to keep from any medium to sealing part.
5) When conveying medium of over high or low temperature,with medium which are easy catch fire,easy for explosion.
Related mechanical seal standards must be referred to take appropriate measures such as quench,rinsing,coolong and
filtrating.
6) Appropricate lubrication must be choosen when mechanical seal is installed.The installment size of the mechanical
seal must be guaranteed to the installment instruction.
7) Before the machine starts running,the hermetic compartment shall be full of medium and well lubricated.Dry friction
which may lead to the damage of the air-tightness is strict forbidden.
